42
Piston Service
Gently clamp the seal head into the vise. Push the compression ball
out of the backside of the seal head through the bleed port.
Do not replace the compression ball at this time; you will
replace it later.
Do not reuse the compression ball.
Clamp the shaft eyelet into a vise and install the Clamp the shaft eyelet into a vise and install the seal head/air piston
onto the damper shaft.
NOTICE
Remote shocks: To prevent damage to the remote cable stop,
position the eyelet in the vise so that the remote cable pulley is clear
of the vise jaws.
Remove the o-ring from the middle of the compression poker. Remove
the o-rings on the valve slider.
Apply grease and install new o-rings.
12
1.5 mm
13
RockShox Dynamic Seal Grease
14
RockShox Dynamic Seal Grease RockShox Dynamic Seal Grease
