SRAM RockShox SIDLuxe Select+ 2P User Manual

53
Mounting Hardware Installation
Insert the threaded rod through the bushing pin then through the shaft Insert the threaded rod through the bushing pin then through the shaft
eyelet so that the bushing pin is positioned between the push pin and eyelet so that the bushing pin is positioned between the push pin and
the eyelet.the eyelet.
Thread the large, open end of the catcher onto the rod until it rests on Thread the large, open end of the catcher onto the rod until it rests on
the eyelet. the eyelet.
Clamp the catcher in a vise or hold it secure with a 13 mm wrench. Clamp the catcher in a vise or hold it secure with a 13 mm wrench.
Use a second 13 mm wrench to thread the push pin along the rod until Use a second 13 mm wrench to thread the push pin along the rod until
it pushes the bushing pin into the shock eyelet bushing. it pushes the bushing pin into the shock eyelet bushing.
Continue to thread the push pin until the bushing pin protrudes from Continue to thread the push pin until the bushing pin protrudes from
both sides of the eyelet an equal amount. both sides of the eyelet an equal amount.
You may need to unthread the catcher slightly to check the bushing You may need to unthread the catcher slightly to check the bushing
pin spacing.pin spacing.
2
3
4
13 mm 13 mm
