RangerSInstallationandtroubleshooting
20
3 Usetheitemselectorstoselect 2. Rain andpushthe ENTER
button.
Now the display looks like this:
4 Nowyoucanchoosebetweenthreesettings:
Raingauge(Pulses)
Ifyourrainsensorprovidesdynamicdatainthesensethatitsendsapulse
foreachunitofrainitdetects,select Pulses .
Raincontact(N/OorN/C)
Ifyourrainsensorsimplytellsthecontrollerwhethertoirrigateornot(if
it'srainingornot),youneedtotellthecontrolleriftheinputisnormally
openorclosed.Wheneverthedeviceisintheoppositemode,the
controllerwillnotirrigate.
Disabled
Don'tusetheRaininput.
Usetheitemselectorstolocatethesettingyouwantandifyouchose
anythingbut Rain gauge (Pulses) ,pushthe ENTER buttontosaveyour
selectionandthe SENSORS buttontoexitsensorconfiguration.
