L6470 Programming manual
Doc ID 16737 Rev 2 47/64
The OC_SD bit sets if an overcurrent event causes or not the bridges to turn-off; the OCD
flag in status register is forced low anyway:
The POW_SR bits set the slew rate value of power bridge output:
The EN_VSCOMP bit sets if the motor supply voltage compensation is enabled or not.
The F_PWM_INT bits set the integer division factor of PWM frequency generation.
Table 24. Overcurrent event
OC_SD Overcurrent event
1 Bridges shut down
0 Bridges do not shut down
Table 25. Programmable power bridge output slew-rate values
POW_SR
[1..0]
Output Slew-rate
(1)
[V/µs]
1. See S
Rout_r
and S
Rout_f
parameters in the electrical characteristics Table 4 for details.
0 0 180
0 1 180
1 0 290
1 1 530
Table 26. Motor supply voltage compensation enable
EN_VSCOMP Motor supply voltage compensation
0 Disabled
1 Enabled
Table 27. PWM frequency: integer division factor
F_PWM_INT
[2..0]
Integer division factor
000 1
001 2
010 3
011 4
100 5
101 6
110 7
111
