Typical applications
L6470
18/64
Doc ID 16737 Rev 2
5 T
ypical
applications
Figure 3.
Bipolar stepper motor
control application using L6
470
T
able 6.
T
ypical applicati
on value
s
Name
value
C
VS
220 nF
C
VSPOL
100
µ
F
C
REG
100 nF
C
REGPOL
47
µ
F
C
DD
100 nF
C
DDPOL
10
µ
F
D1
BA
T46SW or 2x 1N4148
C
BOOT
220 nF
C
FL
Y
10 nF
R
PU
39 k
Ω
R
SW
100
Ω
C
SW
10 nF
R
A
2.7 k
Ω
(VS = 36 V)
R
B
62 k
Ω
(VS = 36 V)
