8 Electrical and performance parameters
In this section, all parameters are not guaranteed: They are extracted from the design phase and the product
validation on a few
STLINK-V3PWR samples. They are not issued from characterization or a calibration process.
8.1 Absolute maximum rating
Table 10. Absolute maximum rating
Parameter Condition Min Max Unit
USB-C supply voltage (VBUS) OVP from 6.5 V -0.3 20 V
Voltage applied on any port Unpowered -0.3 0.7 V
Voltage applied on OUT or AUX port Powered, outputs OFF -0.3 5 V
Voltage applied on T_VCC powered -0.3 4.2 V
Voltage applied on any DEBUG or BRIDGE input
powered,
T_VCC ≤ 3.6V
-0.3
T_VCC +
0.6
V
Storage temperature - -20 80 °C
Operating temperature - 0 50 °C
Relative humidity (non-condensing) - 0 95 %
All voltages are relative to GND with GND internally connected to USB GND.
8.2 Recommended operating conditions
Table 11. Recommended operating conditions
Symbol Parameter Min Typ Max Unit
V
BUS_IN
USB-C supply voltage 4.5 5 5.5 V
I
SUP_USB
USB host port supply current capability (charging
port)
1.5 - - A
H
REL
Relative humidity (non-condensing) 20 - 80 %
T
OP
Operating temperature 15 23 35 °C
8.3 SMU output (OUT) characteristics
All parameters are provided at V
BUS_IN
= 5 V
, T
OP
= 23 °C, and V
OUT
= 3.3 V unless otherwise specified.
8.3.1 SMU voltage source characteristics
Table 12. SMU voltage source characteristics
Symbol Parameter Conditions Min. Typ. Max. Unit
VOUT Output voltage
Programmable range 1.6 - 3.6 V
Programming step - 100 - mV
VOUT_ACC
Output voltage
accuracy
10 nA < I
OUT
< 500 mA
V
OUT
= {1.8 V ; 3.3 V}
- ±2 - %
I
OUT
Maximum
continuous output
current
1.6 V < V
OUT
< 3.6 V
- 500 mA
UM3097
Electrical and performance parameters
UM3097 - Rev 1
page 18/30
