ST STM32

UM1974 Rev 9 57/85
UM1974 Hardware layout and configuration
84
CN9
27 D66 CAN_TX PD1 CAN_1
-
29 D65 I/O PG0 I/O
2 D51 USART_B_SCLK PD7
USART_2
4 D52 USART_B_RX PD6
6 D53 USART_B_TX PD5
8 D54 USART_B_RTS PD4
10 D55 USART_B_CTS PD3
12 GND GND - ground
14 D56 SAI_A_MCLK PE2
(2)
SAI_1_A
16 D57 SAI_A_FS PE4
18 D58 SAI_A_SCK PE5
20 D59 SAI_A_SD PE6
22 D60 SAI_B_SD PE3
SAI_1_B
24 D61 SAI_B_SCK PF8
26 D62 SAI_B_MCLK PF7
28 D63 SAI_B_FS PF9
30 D64 I/O PG1 I/O
Right Connectors
CN7
1 D16 I2S_A_MCK PC6
I2S_2
-
3 D17 I2S_A_SD PB15
3 D17 I2S_A_SD PB15
5 D18 I2S_A_CK PB13
I2S_3 / SPI3
7 D19 I2S_A_WS PB12
9 D20 I2S_B_WS PA15
11 D21 I2S_B_MCK PC7
13 D22
I2S_B_SD/
SPI_B_MOSI
PB5
15 D23 I2S_B_CK/ SPI_B_SCK PB3
17 D24 SPI_B_NSS PA4
19 D25 SPI_B_MISO PB4
2 D15 I2C_A_SCL PB8 I2C1_SCL
ARDUINO
®
support
4 D14 I2C_A_SDA PB9 I2C1_SDA
6 AREF AREF - AVDD/VREF+
8 GND GND - ground
Table 18. NUCLEO-F446ZE and NUCLEO-F722ZE pin assignments (continued)
Connector Pin
Pin
name
Signal name
STM32
pin
Function Remark
