ST STM32 User Manual

UM1974 Rev 9 69/85
UM1974 Hardware layout and configuration
84
Table 21. ST morpho connector for NUCLEO-F207ZG, NUCLEO-F412ZG,
NUCLEO-F413ZH, NUCLEO-F429ZI, NUCLEO-F439ZI, NUCLEO-F446ZE,
NUCLEO-F722ZE, NUCLEO-F746ZG, NUCLEO-F756ZG,
NUCLEO-F767ZI and NUCLEO-H743ZI
CN11 odd pins CN11 even pins CN12 odd pins CN12 even pins
Pin Pin name Pin Pin name Pin Pin name Pin Pin name
1PC102PC111PC92PC8
3 PC12 4 PD2 3 PB8 4 PC6
5 VDD 6 E5V 5 PB9 6 PC5
7BOOT0
(1)
8GND7AVDD8U5V
(2)
9PF610 - 9GND10PD8
11 PF7 12 IOREF 11 PA5 12 PA12
13 PA13
(3)
14 RESET 13 PA6 14 PA11
15 PA14
(3)
16 +3.3 V 15 PA7 16 PB12
17 PA15 18 +5 V 17 PB6 18 PB11
19 GND 20 GND 19 PC7 20 GND
21 PB7 22 GND 21 PA9 22 PB2
23 PC13 24 V
IN
23 PA8 24 PB1
25 PC14 26 - 25 PB10 26 PB15
27 PC15 28 PA0 27 PB4 28 PB14
29 PH0 30 PA1 29 PB5 30 PB13
31 PH1 32 PA4 31 PB3 32 AGND
33 V
BAT
34 PB0 33 PA10 34 PC4
35PC236PC1 35PA236PF5
37PC338PC037PA338PF4
39 PD4 40 PD3 39 GND 40 PE8
41 PD5 42 PG2 41 PD13 42 PF10
43 PD6 44 PG3 43 PD12 44 PE7
45 PD7 46 PE2 45 PD11 46 PD14
47 PE3 48 PE4 47 PE10 48 PD15
49 GND 50 PE5 49 PE12 50 PF14
51 PF1 52 PF2 51 PE14 52 PE9
53 PF0 54 PF8 53 PE15 54 GND
55 PD1 56 PF9 55 PE13 56 PE11
57 PD0 58 PG1 57 PF13 58 PF3
59 PG0 60 GND 59 PF12 60 PF15
61 PE1 62 PE6 61 PG14 62 PF11
