Using IAR Embedded Workbench® for ARM UM1467
17/46 Doc ID 022172 Rev 1
3. Select the Linker category, open the Config tab, in the Linker configuration file pane
select Override default and click Edit to display the Linker configuration file editor.
Figure 15. Linker > Config tab
4. In the Linker configuration file editor dialog box, open the Vector Table tab and set
the .intvec.start variable to 0x08000000.
Figure 16. Linker configuration file editor dialog box > Vector Table tab
5. Open the Memory Regions tab, and enter the variables as shown in Figure 17.
Figure 17. Linker configuration file editor dialog box > Memory Regions tab
6. Click Save to save the linker settings automatically in the Project directory.
