LFBGA448 ball
I/O port
Main function
Motor control connector
A7
PJ13
L
TDC_B1
-
B7
PJ14
L
TDC_B2
-
C7
PJ15
L
TDC_B3
-
D8
PK0
L
TDC_G5
-
E7
PK1
L
TDC_G6
TRACE_D4
E8
PK2
L
TDC_G7
TRACE_D5
B6
PK3
L
TDC_B4
-
A6
PK4
L
TDC_B5
-
C6
PK5
L
TDC_B6
TRACE_D6
A5
PK6
L
TDC_B7
TRACE_D7
B5
PK7
L
TDC_DE
-
G2
PZ0
SPI1_SCK
-
H5
PZ1
SPI1_MISO
-
K5
PZ2
SPI1_MOSI
-
F4
PZ3
SPI1_NSS
-
G1
PZ4
I2C4_SCL
-
H4
PZ5
I2C4_SDA
-
G3
PZ6
SMARTCARD_CLK
-
H3
PZ7
SMARTCARD_IO
-
UM2648
STM32MP157F-EV1 I/O assignment
UM2648
-
Rev 1
page 49/61
48
50
