I/O Configuration
MFX_O2 XSDN – Camera PWDN, active high
1.
Available on the MB1262/CN7 connector, but not used in the MB1379 module
6.18 1 Gbps Ethernet
The STM32MP157F-EV1 board provides a 1 Gbps Ethernet feature by means of an external physical interface
device (PHY), R
TL8211EG-VB-CG. This PHY is connected to the STM32MP157FAA1 gigabit reduced medium-
independent interface (RGMII), and is clocked from a 25 MHz crystal (X1).
The Ethernet PHY is supplied by 3V3. It generates its own supply 1V05 and digital/analog 3V3.
LD1 LED blinks to indicate data transmission.
The Ethernet module connector MB1262/CN6 is for STMicroelectronics internal use only.
6.18.1 RGMII interface
Table 26 describes the I/O configuration for the Ethernet interface.
T
able 26. I/O configuration for the Ethernet interface
I/O Configuration
PD10 PD10 (SUB_NRST) is used as PHY_NRST active Low
PA2 PA2 is used as ETH_MDIO
PG0 PG0 is used as ETH_MDINT
PC1 PB11 is used as ETH_MDC
PA7 PA7 is used as ETH_RX_DV(PHY_AD2)
PC4 PC4 is used as ETH_RXD0
PC5 PC5 is used as ETH_RXD1
PB0 PB0 is used as ETH_RXD2
PB1 PB1 is used as ETH_RXD3
PB11 PB11 is used as ETH_TX_EN
PG13 PG13 is used as ETH_TXD0
PG14 PG14 is used as ETH_TXD1
PC2 PB11 is used as ETH_TXD2
PE2 PE2 is used as ETH_TXD3
PA1 PA1 is used as ETH_RX_CLK
PG4 PG4 is used as ETH_GTX_CLK
PG5 PG5 is used as ETH_CLK125
UM2648
1 Gbps Ethernet
UM2648 - Rev 1
page 28/61
