Appendix B STM32MP157F-EV1 I/O assignment

able 49. STM32MP157F-EV1 I/O assignment

LFBGA448 ball I/O port Main function Motor control connector

AA3 PA0 WAKE_UP -

V4 PA1 ETH_RX_CLK -

AB2 PA2 ETH_MDIO -

T4 PA3 TIM2_CH4 Bus voltage

V6 PA4 ADC1_IN18_DACOUT1 -

U5 PA5 ADC1_IN19_DACOUT2 -

W9 PA6 DCMI_PIXCLK Emergency Stop

Y9 PA7 ETH_RX_DV -

B13 PA8 SDMMC2_D4 -

A11 PA9 SDMMC2_D5 -

Y17 PA10 OTG_ID -

Y16 PA11 I2C5_SCL -

W16 PA12 I2C5_SDA -

W3 PA13 PA13 GPIO -

R3 PA14 PA14 GPIO -

E11 PA15 HDMI_CEC -

AB5 PB0 ETH_RXD2 -

AA5 PB1 ETH_RXD3 -

V13 PB2 UART4_RX -

A12 PB3 SDMMC2_D2 -

C13 PB4 SDMMC2_D3 -

AA8 PB5 SPDIF_TX -

W13 PB6 QSPI_BK1_NCS -

F11 PB7 DCMI_VSYNC -

AB8 PB8 DCMI_D6 PFC PWM

F12 PB9 SDMMC1_CDIR -

V9 PB10 USART3_TX -

Y5 PB11 ETH_TX_EN -

AA7 PB12 USART3_RX -

V10 PB13 DFSDM_CKOUT -

A13 PB14 SDMMC2_D0 -

B12 PB15 SDMMC2_D1 -

U10 PC0 QSPI_BK2_NCS -

AB3 PC1 ETH_MDC -

Y1 PC2 ETH_TXD2 -

U3 PC3 DFSDM_DATA1 -

AB6 PC4 ETH_RXD0 -

UM2648

STM32MP157F-EV1 I/O assignment

UM2648 - Rev 1

page 45/61
