Assignable Input and Output Functions
QB Expert Alpha Controller
138
Outputs
Description
CYCLE NOK
Asserts at the end of a fastening cycle when the achieved torque and/or angle for the Audit step are NOT within
specified limits. Also asserts when the Stop/Abort within Limits parameter is set to Yes and the tool is stopped
or aborted within limits. Resets when the tool is commanded to run again. Can also be reset with the RESET
RESULTS STATUS input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the cycle status comes.
CYCLE OK
Asserts at the end of a fastening cycle when the achieved torque and angle for the Audit step are within
specified limits. Will not assert if the Stop/Abort within Limits parameter is set to Yes and the tool is stopped
or aborted within limits. Resets when the tool is commanded to run again. Can also be reset with the RESET
RESULTS STATUS input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the cycle status comes.
CYCLE STOPPED
Asserts when the tool shuts off due to a loss of Start signal or the operator released the trigger before the target
was achieved. Resets when the tool is commanded to run again. Can also be reset with the RESET RESULTS
STATUS input.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the cycle status comes.
DISASSEMBLY
DETECTED
Asserts when the tool is running in Reverse and the achieved torque value exceeds the Threshold Torque value
through some rotation. Resets when the tool is stopped.
Size: 1 bit
Configuration:
Contact Type: Normally Open (N.O.), Normally Closed (N.C.)
Output Type: Normal, Timed, Flash
Minimum ON Time, Time, Period
Spindle: Type the spindle number from which the disassembly status comes.
