Starline S96v2 - Technical Specifications

User manual
Technical Specifications
Parameter Value
Near Field Communication (NFC) Bluetooth Smart
Remote Key Operating Frequency 868.7–869.2 MHz
Remote Key Control Range Up to 1500 meters
Notification Range on Remote Key Up to 2000 meters
GSM Standard 900–1800 MHz
Antenna Type Built-in
Data Transmission Service GPRS / LTE (Depends on configuration)
Number of SIM Cards 2 x nanoSIM
GPS+GLONASS Receiver Sensitivity -148 dBm (Cold Start)
-163 dBm (Hot Start)
-165 dBm (Tracking Mode)
Interfaces
2 CAN
4 LIN
1 Universal StarLine Bus
1 USB
16 Configurable Channels:
15 Outputs (0.2 A)
2 Outputs (2 A)
3 Positive Inputs
3 Negative Inputs
1 Universal Input
Temperature Sensor Connector
Service Button Connector
Microphone Connector
Input Voltage Range 8–16 V
Power Consumption 10–15 mA
Operating Temperature Range -40°C to +85°C
Main Unit Dimensions 106 x 63 x 17 mm
Weight 63 grams
