Keyboard Depth and Tension Controls
There are two thumbwheels on the Diamante, one on each side of the keyboard, that control the
keyboard depth and keyboard tension.
The depth of stroke adjustment wheel, on the left, determines the height of the number bar and all the
steno keys. This affects how far the keys go down when you press them.
The keyboard tension adjustment wheel, on the right, controls how soft or firm the keys feel. The
extensive range, between the top and bottom stopping positions on the wheel, allows you to customize
the tension to your particular writing touch. Do not force the wheel past either stopping position.
Adjust Depth of Stroke
To adjust the depth of stroke:
1. Face the front of the Diamante.
2. Do one of the following:
• To shorten the stroke depth, roll the left thumbwheel toward the front of the Diamante.
• To lengthen the stroke depth, roll the left thumbwheel toward the back of the Diamante.
Adjust Keyboard Tension
To adjust the keyboard tension:
1. Face the front of the Diamante.
2. Do one of the following:
• To decrease keyboard tension for a softer touch, roll the right thumbwheel toward the front of the
Diamante.
• To increase keyboard tension for a firmer touch, roll the right thumbwheel toward the back of the
Diamante.
