iAStar Frequency Inverter For Elevator Door Machine manual Instructions
29
F20 Deceleration of closing door range：1-30
Deceleration of declining segment in the door-closing curve when door is
closing.
F21 Deceleration of crash-stop range：1-50
Deceleration of declining segment in the door-closing and door-opening curve
when door is closing and opening.
F22 Crawl distance of opening door range：1-30
The percentage of the starting segment indoor-opening curve and door width.
F23 Crawl distance of closing door range：1-30
The percentage of the starting segment indoor-closing curve and door width.
F24 Deceleration position of door openning range：50-100
The percentage of the declining segment in door-opening curve and door width.
F25 Deceleration position of door closing range：1-50
The percentage of the declining segment in door-closing curve and door width.
F26 Close delay range：0-30000
If the Colse signal is issue，The door will close after F26.
F27 Open delay range：0-300.00
If the Open signal is issue，The door will open after F26.
F28 Speed of closing retiring cam range：0-300
Rotate speed of closing retiring cam when the signal of door open limit is given
F29 Limit Torque of door closing range：1-300
In the case of Door-blocked or person-nipped, the inverter will open the door
first then close the door. The smaller you set to the parameter of limit Torque of door
closing , the more sensitive protect will be.But if the parameter was set too small,
Door-blocked protect would work frequently
F30 Holding Torque of door opening range：0-30
To setting the value of holding torque of door opening, the bigger the value is,
the bigger the holding torque is.
F30 = 0，Opening door without holding torque. The inverter stops after the door
opens to position.
F30 = 1～30%，The inverter continues to open the door at the door-opening speed,
until there is a closing signal.
F31 Holding Torque of door closing range：0-30
To setting the value of holding torque of door closing, the bigger the value is, the
bigger the holding torque is.
F31 = 0，Closing door without holding torque. The inverter stops after the door
