Tech Support: www.steppir.com/support Tel: 425.891.6134 support@steppir.com
Page 13
QTY PART NUMBER DESCRIPTION
12 10-1601-22 2” Aluminum saddle half
14 60-0046 5/16” Nylock nut
14 60-0114 5/16 X 3-3/4 ” Stainless steel hex head bolt
1 60-0085 3/8” X 4” Stainless steel all-thread hex head bolt
1 60-0049 3/8” Stainless steel nut
2 60-0050 3/8” Nylock nut
4 60-0034 3/8” Stainless steel washer
4 60-0113 10-32 X 5/8” Stainless steel machine screw
50 60-0112 10-32 SS set screw
(use one set screw per pair of saddles)
Mast Plate Hardware Kit
72-0040-01
QTY PART NUMBER DESCRIPTION
1 72-0009-03 Glue kit
2 09-0001 66’ PVC electrical tape
2 10-1028-01 Anti-Seize
4 10-1509-02 Diverter cone
Glue, Tape & Anti-Seize Kit
72-0041-01
ASSEMBLY KITS- BILL OF MATERIALS (continued)
