Page 14
QTY PART NUMBER DESCRIPTION
1 21-6301-96 11’ 6” Coax jumper (Reflector element)
1 21-6301-80 8’ Coax Jumper for (Director element)
1 21-6301-30 4 ft Coax Jumper (Driven element)
1 03122 3 ft length 4 conductor control
Coax Antenna Switch Cable Kit*
72-0042-11
QTY PART NUMBER DESCRIPTION
1 70-3001-01 Antenna switch w/ gasket, hardware and relay board
1 10-1619-01 Coax switch bracket
2 10-1601-22 2” Aluminum saddle half
2 60-0065 5/16” X 3 1/2” Stainless steel hex head bolt
2 60-0046 5/16” Nylock nut
3 60-0113 10-32 X 5/8” Stainless steel machine screw
3 60-0019 10-32 Nylock nut
Coax Antenna Switch Hardware Kit
72-0042-01
ASSEMBLY KITS- BILL OF MATERIALS (continued)
*This kit is not in a bag. The kit consists of the jumpers and the control cable, wrapped together for ship-
ping purposes.
