4-9
Installation Operator/Maintenance Manual P129391-130
STEP 3: Measure gap between ends of the loading car and outside
surface of both endframes.
• Gaps should be equal at both ends.
• If not, move front caster stops by half the difference of
largest gap end.
• Lift Loading car and withdraw from chamber.
• Reinsert and lower onto the chamber tracks and verify
loading car is centered to within about ¼" (6 mm) and
lies within outer endframe surface when lowered.
• Adjust front caster stops as required.
STEP
3
Loading Car
Sterilizer Chamber
Measure gap at either end.
Gaps should be equal.
To Next Page
