Thecrankshaft(1),connecting
rod(2)andneedlebearing
formaninseparableunit.
Itmustalwaysbereplacedasa
completeunit.
-Whenfittingareplacement
crankshaftalwaysinstallnewoil
sealsandballbearings.
•
Pullofftheoilseals(1)andball
bearings(2).
-Removethewashers.
•
Slipwashers(1)ontorightand
leftcrankshaftstubs.
•
Heatballbearings(2)toapprox.
50°C(120°F)andpushthem
homeasfarasstop.
-Lubricatesealinglipsofoilseals
withgrease-see11.2.
•
Slidetheoilseals,opensides
facingtheballbearings,over
theendsofthecrankshaft.
-Thoroughlycleanthesealing
facesonthecrankcaseand
enginepantoremovealltraces
ofsealant.
•
Placecrankshaftinthecrank-
casesothattheconnectingrod
(1)pointstothecylinderside
andtheshortcrankshaftstub(2)
isatthewideside(arrow)ofthe
crankcase.
•
Applyathinbeadofsealantto
theenginepan’smatingface-
see11.2.
Important:Followmanufacturer’s
instructions.
-Fittheenginepanandclampit
tothecrankcasewiththepuller-
see5.5.1.
Assembleallotherpartsinthe
reversesequence.
VA
232RA132
1
2
VA
232RA134
22 1
VA
232RA135
VA
232RA137
VA
232RA133
21 12
VA
232RA136
1 2
FS45 17

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
