Stihl FS 45 Manual

Removing
Troubleshootingchart-see
"StandardRepairs,Trouble-
shooting"handbook.
-Removethedrivetube-
see10.2.
-Removethefueltank-see9.4.
•
Takeoutscrewsatfrontendof
shroud.
•
Takeoutscrewsatrearendof
shroud.
•
Liftawaytheshroud.
•
Disconnecttheshortcircuit
wire(1)andgroundwire(2)
fromtheignitionmodule.
•
Removethrottlecable(1)nipple
fromslottedpin(2)onthrottle
lever.
•
Takethrottlecableoutof
tensioner.
•
Takeoutthescrews(1).
-Removetheenginehousing.
Note:Removescrew(2)onlyif
damaged.Tightendownnew
screwto4.5Nm(3.3lbf.ft).
-Pulloffthesparkplugboot.
-Unscrewthesparkplug.
•
Fitlockingstrip(1)
42218935900insparkplug
hole.
4. CLUTCH
4.1 RemovingandInstalling
VA
232RA004
VA
232RA007
VA
232RA002
VA
232RA005
2
1
VA
232RA008
2
1
1
VA
232RA003
VA
232RA006
2
1
VA
232RA009
1
6 FS45

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
