Installinthereversesequence.
Positiontorsionspringinthrottle
triggerrecessasshown.
-Removethethrottletrigger-
see8.1.
Disconnectthrottlecable(1)
nipplefromtheslottedpin(2)
onthethrottlelever.
Takethethrottlecableoutof
thetensioner.
Takethethrottlecableoutofthe
rearpartoftheenginehousing.
Removethethrottlecablefrom
thefrontpartoftheengine
housing.
Installinthereversesequence.
Engagetheprotectivesleevefor
thethrottlecableproperlyinthe
enginehousing’sfrontguide.
Locatethrottlecable’sprotective
sleeveintheretainers.
-Checkthatrestofthrottlecable
isproperlyroutedandseated.
8.2 ThrottleCable
8.2.1 Replacing
VA
232RA073
VA
232RA006
2
1
VA
232RA075
VA
232RA007
VA
232RA074
VA
232RA138
26 FS45
