Takeoutscrew(1).
•
Pullofftheclamp(2).
Installinthereversesequence.
-Degreaseclampmountingarea.
•
Pushdrivetubeintohousingso
thattheholeslineup.
Note:Illustrationshowsdrive
tubenexttoenginehousing.
-Turnthebearinghousingback
andforthwhilepushingthedrive
shafthomesothatthesquare
endoftheflexibleshaftengages
theclutchdrum’ssquaresocket.
-Insertfixingscrewandtighten
downto2.0Nm(1.5lbf.ft).
-Tightendownclampscrewson
enginehousinganddeflectorto
8.0Nm(5.9lbf.ft).
Theflexibleshaftissupportedina
linerinsidethedrivetube.
-Removethedrivetube-
see10.2.
•
Pulltheflexibleshaftoutofthe
drivetube.
Note:Iftheshafthasturnedblue,
fitanewone.
-Coattheflexibleshaftwith
STIHLgearlubricant
07811201117,see11.2,before
installation.
Important:Applythegrease
uniformlyandthinlytothewhole
flexibleshaft.Donotpumpgrease
directlyintothedrivetube.
•
Pushtheflexibleshaftintothe
drivetubeuntilitisflushwiththe
endofthedrivetube.
-Installthedrivetube-see10.2.
10.3 FlexibleShaft
VA
232RA109
1
2
VA
232RA112
VA
232RA110
VA
232RA111
FS45 33
