-Removetheairfilter-see9.1.
•
Usescrewdriver59108902420
tounscrewnuts.
-Liftawaythefilterhousing.
•
Disconnectthrottlecable(1)
nipplefromslottedpin(2)onthe
throttlelever.
•
Pullthefuelhosesofftheelbow
connectors.
•
Removethecarburetor.
•
Removethegasket.
Installinthereversesequence.
-Useanewgasket.
-Fitfuelhosessothattheyare
notkinkedorpinched.
-Tightenfilterhousingnutsto
3.5Nm(2.6lbf.ft).
Thecarburetorhasnoadjusting
screwsformaximumengine
speed(Hscrew)oridlemixture
(Lscrew).
Thecarburetoristunedsothat
theenginereceivesanoptimum
fuel-airmixtureinalloperation
conditions.
Standardsetting
Ifthecarburetorhastobe
adjustedfromscratch,firstcarry
outthestandardsetting.
•
Carefullyscrewidlespeedscrew
(LD)downontoitsseat.
•
Nowopentheidlespeedscrew
(LD)twofullturns.
Aslightcorrectionoftheidle
speedmaybenecessary.Usethe
followingprocedure:
-Mountapprovedcuttingtool.
-Checktheairfilter,replaceif
necessary.
-Checksparkarrestingscreen,
cleanorreplaceasnecessary.
-Starttheengineandallowitto
warmup.
9.2.2 RemovingandInstalling 9.2.3 Adjusting
VA
232RA085
VA
232RA088
VA
232RA086
2
1
VA
232RA089
VA
232RA090
LD
VA
232RA087
FS45 29
