-Removestartercoverwith
rewindstarter-see7.2.1.
Starterrope
-Removetheroperotor-see
"StandardRepairs,Trouble-
shooting"handbook.
-Removethestarterropefrom
therotor.
Easecapoutofstartergrip.
-Pullropeoutofstartergrip.
Threadendofnewstarterrope
throughtheundersideofthe
startergrip.
-Secureendofropewithasimple
overhandknot.
Pulltheropebacktolocatethe
knotinthestartergrip.
-Pushcapintostartergrip.
-Securestarterropetoroperotor.
-Installtheroperotor.
Startergrip
Thestartergripissuppliedwith
starterrope.
-Removetheroperotor-see
"StandardRepairs,Trouble-
shooting"handbook.
-Pulltheknotoutoftherecessin
theroperotor.
-Undotheknotandpulltherope
outoftherotorandfanhousing.
Threadthestarterrope
00001958200throughthe
guidebushfromoutside.
Threadropethroughtheholein
thesideoftherotor.
-Securethestarterropewitha
simpleoverhandknot.
Pulltheropebackintotherotor
sothattheknotlocatesinthe
recess.
-Installtheroperotor-see
"StandardRepairs,Trouble-
shooting"handbook.
-Tensiontherewindspring-
see7.2.2.
-Fitstartercoverwithrewind
starter-see7.2.2.
7.3 StarterRope/StarterGrip(ElastoStart)
VA
362RA097
VA
250RA127
VA
362RA095
VA
250RA128
VA
362RA096
VA
232RA063
24 FS45
