Stihl FS 45 Manual

-Removethefiltercover-see9.1.
•
Pullfuelhosesofftheelbow
connectors.
-Removethestartercover-
see7.2.1.
-Removethefueltank.
•
Removetheplugsfromthefuel
tank.
Note:Replacewornplugs.
•
Takeoutscrew(1).
•
Removetheretainer(2).
Note:Tightendownthescrew
onlyafterfittingthestartercover.
•
Pulloutthebush(1).
•
Removegrommet(2)fromtank.
-Removethefuelhoses-see9.5.
Installinthereversesequence.
•
Theplugs(1)mustengage
overthepegs(2).
-Donotpinchthethrottlecable.
•
Tightendownscrewonretainer
to4.0Nm(3lbf.ft).
Thediaphragmpumpdrawsfuel
outofthetankandintothe
carburetorviathefuelhose.Any
impuritiesmixedwiththefuelare
retainedbythepickupbody(filter).
Thefineporesofthefilterevent-
uallybecomecloggedwithminute
particlesofdirt.Thisrestrictsthe
passageoffuelandresultsinfuel
starvation.
Important:Intheeventoftrouble
withthefuelsupplysystem,
alwayscheckthefueltankand
thepickupbodyfirst.Cleanthe
fueltankifnecessary.
Cleaningthefueltank
-Unscrewthefillercapanddrain
thetank.
-Pourasmallamountofclean
gasolineintothetank.
-Closethetankandshakethe
unitvigorously.
-Openthetankagainanddrainit.
Note:Disposeoffuelproperly.
Pickupbody/fuelhoses
-Removethefueltank-see9.4.
Note:Markthepositionofthefuel
hoses.
•
Easethegrommetoutofthe
tankhousing.
9.4 FuelTank 9.5 PickupBody/FuelHoses
VA
232RA094
VA
232RA095
VA
232RA096
1
2
VA
232RA097
2
1
VA
232RA098
2
2
1
1
VA
232RA099
VA
232RA100
FS45 31

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
