Stihl FS 45 Manual

Shortcircuitwire/groundwire
-Removethestopswitch.
•
Disconnecttheshortcircuitwire
(1)andgroundwire(2)
fromtheignitionmodule.
-Takethewiresoutofengine
housing.
Installinthereversesequence.
•
Makesurewiresareproperly
seatedintheguidesinthe
enginehousing.
•
Engagewiresbehindretainersin
areaofflywheel.
Iftheactionofthestarterrope
becomesverystiffandtherope
rewindsveryslowlyornotcom-
pletely,itcanbeassumedthat
thestartermechanismisinorder
butpluggedwithdirt.Atverylow
outsidetemperaturesthelubri-
catingoilontherewindspringmay
thickenandcausethespring
windingstosticktogether.This
hasadetrimentaleffectonthe
functionofthestartermechanism.
Insuchacaseitissufficientto
applyafewdropsofparaffin
(kerosine)totherewindspring.
Thencarefullypulloutthestarter
ropeseveraltimesandallowitto
rewinduntilitsnormalsmooth
actionisrestored.
Ifcloggedwithdirtorpitch,the
entirestartermechanism,
includingtherewindspring,must
beremovedanddisassembled.
Takespecialcarewhenremoving
thespring.
Washallpartsinparaffinorwhite
spirit.
Lubricatetherewindspringand
starterpostwithSTIHLspecial
lubricant,see11.2,before
installing.
7. REWINDSTARTER
7.1 General
VA
232RA005
2
1
VA
232RA054
VA
232RA053
FS45 21

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
