Installingtheflywheel:
Important:Cleanthestubofthe
crankshaftandtheflywheelhub
borewithastandardcommercial,
solvent-baseddegreasant
containingnochlorinatedorhalo-
genatedhydrocarbons-see11.2.
-Fittheflywheel.
Note:Checkpositionofslot.
-Installtheclutch-see4.1.
-Pulllockingstripoutofcylinder.
-Fitsparkplugandtorquedown
to
20Nm(15lbf.ft).
Important:Ifthesparkplug
comeswithaseparateterminal
nut,alwaysfitthenutonthe
threadandtightenitdown
securely.
-Fitthebootonthesparkplug.
Stopswitch
-Removetheshroud-see4.1.
•
Pressdowntheinterlock
lever(1).
•
Pullthebase(2)outofthe
enginehousing.
•
Unhookthewires(1)fromthe
retainer(2).
•
Easethestopswitch(3)outof
thebase.
•
Disconnecttheshortcircuitwire
andgroundwirefromthestop
switch.
Installinthereversesequence.
-Pressdowntheinterlocklever.
•
Fitthebasesothatits
pegs(1)engagetheholes(2).
6.3 StopSwitch/ShortCircuitWire/
GroundWire
VA
250RA008
VA
232RA049
21
VA
232RA051
VA
232RA052
1
1
2
VA
232RA050
3
1
2
20 FS45

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
