-Removetheshroud-see4.1.
Disconnectshortcircuitwire(1)
andgroundwire(2)fromthe
ignitionmodule.
-Pullbootoffthesparkplug.
Takeoutthescrews.
-Removetheignitionmodule.
Note:Theignitionleadismolded
totheignitionmodule.
-Placetheignitionmodulein
position,insertthescrewsbut
donottightenthemdownyet.
Secureconnectortag(1)for
shortcircuitwirewithupper
screw.
Slidethesettinggauge(1)
11278906400betweenthe
armsoftheignitionmoduleand
theflywheelmagnetpoles.
-Presstheignitionmodule
againsttheflywheelandtighten
downthemountingscrewstoa
torqueof4.5Nm(3.3lbf.ft).
Assembleallotherpartsinthe
reversesequence.
Removingtheflywheel:
-Removetheclutch-see4.1.
Freeofftheflywheelbylightly
tappingtheendofthecrankshaft
stubwitharubbermallet.
-Pullofftheflywheel.
Inspecttheconditionofthe
flywheel(1)andmagnetpoles(2).
Ifyoufindanydamage(cracks
etc.),fitanewflywheel.
6.1.2 RemovingandInstalling 6.2 Flywheel
VA
232RA005
2
1
VA
232RA046
2
1
232RA047
VA
VA
232RA045
VA
232RA048
1
2
FS45 19
