Stihl FS 45 Manual

-Removethestartercover-
see7.2.1.
-Unscrewthesparkplug.
•
Fitlockingstrip(1)
42218935900insparkplug
hole.
•
Unscrewthestartercup.
•
Fitstartercupandtorquedown
to17.0Nm(12.5lbf.ft).
Installallotherpartsinthereverse
sequence.
-Removebaseforstopswitch
andinterlocklever-see6.3.
Interlocklever
•
Easetheinterlockleveroutof
base.
•
Taketheinterlockleveroutof
thebase.
•
Checkthetorsionspringandfita
newoneifnecessary.
Installinthereversesequence.
Throttletrigger
-Removebaseforstopswitch
andinterlocklever-see6.3.
•
Pullthrottletriggeroutofseatin
theenginehousing.
•
Pushlever(1)towardsthrottle
triggerandthentakethetrigger
outoftheenginehousing.
•
Removethetorsionspring(2).
•
Disconnectthrottlecablefrom
trigger.
7.4 StarterCup 8.THROTTLECONTROL
8.1 InterlockLever/ThrottleTrigger
VA
232RA064
1
VA
232RA067
VA
232RA070
VA
232RA065
VA
232RA068
VA
232RA071
21
VA
232RA066
VA
232RA069
VA
232RA072
FS45 25

Stihl FS 45 Specifications

General

Engine Displacement	27.2 cc
Power Output	0.75 kW
Cutting Diameter	380 mm
Engine Type	2-stroke
Shaft Type	Curved
Fuel Capacity	0.33 liters
Fuel Tank Capacity	0.33 liters
Cutting Width	380 mm
Engine Power	1.0 bhp
Vibration Levels Left/Right Handle	5.5/5.5 m/s²
