Stihl HSE 71

30 HSE 61, HSE 71, HSE 81
6. Housing and Handles
6.1 Opening the housing
6.1.1 Removing the top cover
: Take out the screws (1).
: Remove the cover (1).
11
1
6.1.2 Removing the loop
handle
– Remove the cutting attachment,
b 4.1.1.
: Take out the screws (1).
: Squeeze the loop handle (1)
together in direction of arrow and
hold in that position.
1
1
1
: Lift the loop handle (1) with hand
guard slightly to the rear and pull
them forwards at the same time.
6.1.3 Removing the cap
: Take out the screw (1).
1
1
