32 HSE 61, HSE 71, HSE 81
: Push the blue wire (1) into the
two slots (2) in the housing and
secure in position.
: Fit the housing half (1).
1
2
2
1
: Fit the five screws (1) (1.4 Nm).
6.2.2 Installing the motor
housing
: Fit the motor housing (1) from the
front so that it engages the guide
slots.
1
1
1
1
1
1
6.2.3 Installing the cap
: Poisition the cap in the housing –
the rib (1) must locate between
the terminal block and housing.
: Fit the screw (1).
1
1
