60 HSE 61, HSE 71, HSE 81
8.5 Tightening torques
DG and P (Plastoform) screws are used in polymer and light metal components. These screws form a
permanent thread when they are installed for the first time. They can be removed and installed as often as
necessary without impairing the strength of the screwed assembly, providing the specified tightening torque is
observed.
For this reason it is essential to use a torque wrench.
Fastener Thread size For component Torque
Nm
Screw
head
Electrical System
- - Connecting cord and wires to terminal
block, b 3.2.2
0.5 (±0.1) Slot
Cutting attachment:
Spline screw IS-SP5x25
IS-SP5x30
Cutting attachment, b 4.1.2 2.9 (±0.2) TX 25
Spline screw IS-SP5x16 Securing bottom cover,
b 4.1.2
2.9 (±0.2) TX 25
Spline screw IS-PL4x16 Securing bottom cover,
b 4.1.2
1.5 (±0.1) TX 20
Housing and handles:
Spline screw IS-PL4x16 Closing the housing, b 6.2.1. 1.4 (+0.2) TX 20
Spline screw IS-PL4x12 Closing the rear handle, b 6.4.4 1.1 (+0.2) TX 20
Spline screw IS-PL4x16 Mounting the loop handle, b 6.2.5 1.5 (±0.2) TX 20
Spline screw IS-PL4x16 Fitting the top cover, b 6.2.4. 1.2 (±0.1) TX 20
Motor:
Spline screw IS-PL4x16 Installing the gearbox plate, b 5.4.2. 1.5 (+0.2) TX 20
Switch components:
Spline screw IS-PL4x16 Assembling the control unit,
b 7.2.2
1.5 (+0.2) TX 20
Bearing plate:
Spline screw IS-SP4x14 Mounting the cutting attachment,
b 4.1.2
2.9 (±0.2) TX 20
