37HSE 61, HSE 71, HSE 81
6.4.3 Assembling the rear
handle
: Assemble the two sliding
components (1) and (2).
: Engage the switch rod (1) in the
rear sliding component (2).
1
2
1
2
1
2
: Insert support (1) through both
sliding components from the rear.
: Thread the cable (1) through the
sliding components (2).
1
1
2
: Position cable (1) between
housing rib (2) and the support
(3).
1
3
2
