100 MS 271 C, MS 291 C
: Remove the fuel hose (1),
b
12.11.2.
: Press out the fuel return hose (1)
in direction of tank housing.
: Pull out the connector (1) with
fuel return hose (2).
2710RA302 TG
1
2710RA303 TG
1
2710RA304 TG
2
1
: Pull the connector (1) off the fuel
return hose (2).
: Pry out the grommet (1).
– Replace the fuel return hose.
Check the connector and
grommet and replace if
necessary.
: Remove the fuel suction
hose (1), b 12.11.2
5902RA491 TG
2
1
1
2710RA305 TG
1
2710RA306 TG
Installing
: Install the fuel suction hose (1),
b
12.11.2
– Use STIHL press fluid to simplify
assembly, b 14
: Fit the grommet (1) in the
hole (arrow) in the fuel tank and
make sure it is properly seated.
: Push the connector (1) into the
fuel return hose (2) as far as stop.
1
2710RA307 TG
1
2710RA308 TG5902RA447 TG
2
1

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
