68 MS 271 C, MS 291 C
9.4.2 Buffers on Filter Base
– Remove the filter base, b
12.3
: Take out the screw (1).
: Press the tank housing (2) down
a little and hold it there.
: Push out the buffers (1) from the
underside (arrows).
– Check the buffers (1) and replace
if necessary
2
2710RA180 TG
1
2710RA181 TG
1 1
Installing
– Position the buffers (1)
with their tapered ends facing the
bores.
– Use STIHL press fluid to simplify
assembly, b
14
: Push the tapered ends of the
buffers (1) fully into the
bores (arrows).
The tapered ends (arrows) must be
properly seated on the other sides
of the bores.
2710RA182 TG
1 1
2710RA183 TG
– Push the tank housing (2)
upwards and hold it there.
: Insert and tighten down the
screw (1) firmly.
– Reassemble all other parts in the
reverse sequence.
9.5 Install new handlebar
– Remove the shroud, b
6.4
– Remove AV spring from
handlebar, b
9.3
: Take out the screw (1) and
remove the chain catcher (2).
2
2710RA184 TG
1
2
1
2710RA185 TG
