Stihl MS 271 Manual

95MS 271 C, MS 291 C
12.10 Tank Vent
12.10.1 Testing
If problems occur on the carburetor
or the fuel supply system, also
check and clean the tank vent and
replace it if necessary. Check
function by performing pressure and
vacuum tests on the tank via the fuel
hose.
– Open the fuel tank cap and drain
the fuel tank, b
1.
– Close the tank cap.
– Remove the carburetor, b
12.5
: Push the
nipple (1) 0000 855 9200 into the
fuel hose (arrow).
Models with manual fuel pump
: Use a suitable plug (2) to seal the
fuel suction hose (1).
2710RA293 TG
1
2710RA294 TG
1
2
Vacuum test
: Push the ring (1) to the left and
connect the pump (2)
0000 850 1300 to the
nipple (arrow)
– create a vacuum in the fuel
tank.
Equalization of pressure takes
place via the tank vent. There must
be no buildup of vacuum in the tank.
– Clean the area around the tank
vent.
– If necessary, install a new tank
vent or tank, b
12.10 or
b 12.11.5.
Pressure test
: Push the ring (1) to the right and
connect the pump (2)
0000 850 1300 to the
nipple (arrow)
– pressurize the fuel tank.
2710RA295 TG
1
2
2710RA296 TG
1
2
– Operate the pump until the
pressure gauge indicates a
pressure of 0.5 bar. If this
pressure remains constant for at
least 20 seconds, the tank,
including the tank vent, is airtight.
If the pressure drops, the leak
must be located and the faulty
part replaced.
– Reassemble in the reverse
sequence.
12.10.2 Removing and Installing
– Remove the shroud, b
6.4
: Take out the screw (1).
: Press the tank housing (1)
downwards and use wooden
block (2) 1108 893 4800 to
maintain the gap.
2710RA297 TG
1
2710RA298 TG
1
2

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
