Stihl MS 271 Manual

75MS 271 C, MS 291 C
10.3.3 Choke Rod
– Remove the air filter, b
12.1
: Set switch lever (1) to cold start
and block lever (3) on choke
shaft.
: Push the switch lever (1) in the
direction of "
0"
– the choke rod (2) comes out of
its seat (arrow).
: Disconnect the choke rod (2)
from the lever (3).
– Check the choke rod and replace
it if necessary
Installing
: Engage the choke rod (1) in the
bore (arrow) in the choke
shaft (2).
2710RA196 TG
1
3
2
5902RA338 TG
1
2
: Position the choke rod (1) in the
guide (arrow).
– Move the switch lever (2) in
direction of cold start until the
choke rod (1) snaps into position.
– Check operation.
Check that the choke rod is properly
seated.
– Reassemble all other parts in the
reverse sequence.
10.3.4 Throttle Rod
– Remove the throttle trigger,
b
10.2,
QuickStop Super, b
10.3
– Remove the baffle, b
12.2
: Pry the filter base (1) out of the
buffer (2).
5902RA339 TG
1
2
2710RA198 TG
2
1
: Swing the filter base (1) in
direction of throttle trigger until it
is clear of the studs.
– Swing the filter base (1) in
direction of throttle trigger until it
is clear of the studs.
: Swing the filter base (1) in
direction of ignition side and rest
it against the stud (arrow).
: Pry the throttle rod (1) out of the
carburetor carrier (2).
2710RA199 TG
1
2710RA200 TG
1
2710RA201 TG
2
1

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
