76 MS 271 C, MS 291 C
: Pull the throttle rod in the
direction of the rear handle until
its bent end (1) is at the
opening (arrow).
: Rotate the throttle rod (1) about
90° counterclockwise. Pass the
throttle rod (1) through the
opening (arrow) in the direction
of the tank housing and remove
it.
– Check the throttle rod and
replace if necessary
2710RA202 TG
1
2710RA203 TG
1
Installing
: Line up the throttle rod (1) (see
illustration).
: Push the throttle rod (1) between
the tank housing and air guide
shroud and rotate it about 90° at
the same time.
: Pass the throttle rod (1) through
the opening (arrow).
: Turn the bent end (1) clockwise
and push it under the throttle
trigger in the direction of the
engine.
2710RA204 TG
1
2710RA205 TG
1
: Push the throttle rod (1) into the
guide (2) in the carburetor carrier
until it snaps into position.
– Install the throttle trigger, b
10.2
– Install the filter base, b
12.3
– Check operation.
– the throttle lever on the
carburetor must move upwards
when then throttle trigger is
pulled.
– Reassemble all other parts in the
reverse sequence.
2710RA206 TG
2
1

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
