69MS 271 C, MS 291 C
: Remove the screws (1) from the
underside of the machine.
: Push the handlebar (2) sideways
and pry the AV spring (1) out of its
bearing seat (arrow).
– Take out the screws.
: Ease the handlebar (1) sideways
and take it out of the guide
(arrow).
5902RA258 TG
1
1
5902RA259 TG
1
2
2710RA187 TG
1
: Push the handlebar (1) out of the
lower guide.
– Remove the handlebar (1), check
it and replace if necessary.
– Check the annular buffer and
replace it if necessary, b
9.1
Installing
: Push the handlebar, buffer (1)
first, into the engine housing.
: Push the AV spring (1) into its
seat (2).
0001RA232 TG
1
2710RA188 TG
1
2710RA189 TG
2
1
: Position the handlebar (1)
against the guide (arrow).
: Ease the handlebar (1) sideways
and place it in the guide (arrow).
– Insert the screws and tighten
them down firmly.
: Insert and tighten down the
screws (1) firmly.
– Reassemble all other parts in the
reverse sequence.
2710RA190 TG
1
2710RA191 TG
1
5902RA258 TG
1
1

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
