105MS 271 C, MS 291 C
: Fit the antivibration spring (1) in
the recess (arrow) in the engine
housing.
: Push the tank housing (1)
towards the ignition side and turn
it until the peg (2) is inside the
bore (arrow).
– Install the handlebar, b
9.5
: Lift the tank housing (2).
: Insert and tighten down the
screw (1) firmly.
2710RA319 TG
1
2710RA321 TG
2
1
2
2710RA184 TG
1
: Push the connector (1) with fuel
return hose (2) into the fuel return
hose (3) so that the
contours (arrows) are in
alignment.
– Install the stop buffer, b
9.4
– Reassemble all other parts in the
reverse sequence.
5902RA488 TG
1
2
3

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
