Stihl MS 271 Manual

55MS 271 C, MS 291 C
Check the flywheel:
– Have pole shoes turned blue?
– Install new flywheel if necessary,
b 7.6
Air gap:
– Check ignition module/flywheel,
– reset if necessary, b 7.3
Check the ignition lead:
– Severe chafing?
– Spark plug boot: Holes/cracks?
– Resistance: spark plug boot to ground:
spec. 1.5 – 12 kΩ
– Check resistance of ignition lead (spark plug
boot and ignition module removed)
Spec.: < 10 Ω,
If necessary, install new spark plug boot and/or
ignition module,
b 7.5
Check short circuit wire:
– Wire damaged?
– Connectors firmly seated?
– Check continuity, replace wiring harness if
necessary, b 7.7.1
1
3
yes
no
2
Powerful
spark?

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
