78 MS 271 C, MS 291 C
: Pull the worm (1) with drive
spring (2) out of the oil pump.
– Check the spring and worm and
replace if necessary.
: Take out the screws (1) and lift
the oil pump (2).
: Pull the oil pump (1) off the oil
suction hose (2).
– Check the oil pump (1) and
replace it if necessary
2
1
2710RA246 TG
1
1
2710RA248 TG
2
2
1
2710RA249 TG
Installing
: Replace the sealing ring (1) –
always use a new sealing ring.
: Position the oil suction hose (1)
so that the lugs (arrows) are in
alignment.
: Push the oil suction hose (1) onto
the nipple.
2710RA250 TG
1
1
2710RA251 TG
: Position the oil pump (1) so that
its rear connector (arrow)
engages the bore.
: Insert and tighten down the
screws (2) firmly.
– Push the worm fully home.
: Push the washer (1) into position.
Installed position is correct when
"TOP" (arrow) faces outwards.
– Reassemble all other parts in the
reverse sequence.
1
2
2
2710RA252 TG2710RA253 TG
1

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
