81MS 271 C, MS 291 C
– Check the buffers (1) and replace
if necessary, b
9.4.2
Installing
– Fit the contact spring, b
7.7.4
– Use STIHL press fluid to simplify
assembly, b
14
: Engage the filter base (1) in the
buffer (2) – make sure the peg (3)
is properly seated in the buffer.
Engage peg of filter base (1) in
buffer (arrow) at ignition side.
2710RA260 TG
1 1
2710RA261 TG
1
2
3
2710RA207 TG
1
: Push the short short circuit (1)
through the opening (arrow).
: Position the short circuit wire (1)
so that it is above the ground
wire's flag terminal (arrow).
: Push the filter (1) onto the studs
and the carburetor (2).
2710RA262 TG
1
2710RA263 TG
1
2710RA208 TG
1
2
– Use STIHL press fluid to simplify
assembly, b
14
: Engage the filter base (1) in the
buffer (2).
– Reassemble all other parts in the
reverse sequence.
2710RA210 TG
2
1

Stihl MS 271 Specifications

General

Motor type	2-stroke motor
Chain gauge	1.6 mm
Chain pitch	3/8 \
Blade length	400 mm
Automatic oiling	Yes
Oil tank capacity	0.24 L
Fuel tank capacity	0.5 L
Engine displacement	55.5 cm³
Engine power	3.8 hp
Power source	Gasoline

Weight and Dimensions

Weight	5600 g
