MSA 200 C
English
74
The light emitting diode (1) on charger
glows continuously green or flashes red.
Green continuous light ...
... indicates the following:
The battery
– is being charged
– is too hot and must cool down
before charging
See also "Light Emitting Diodes (LEDs)
on Battery".
The green light emitting diode on the
charger goes off as soon as the battery
is fully charged.
Red flashing light ...
... indicates the following:
– No electrical contact between
battery and charger – remove and
refit the battery
– Malfunction in battery – see also
"Light Emitting Diodes (LEDs) on
Battery".
– Malfunction in charger – have
checked by a servicing dealer.
STIHL recommends a STIHL
servicing dealer.
When delivered, the battery is not fully
charged.
It is advisable to charge the battery
completely before using it for the first
time.
N Before inserting the battery, remove
the battery compartment cover if
there is one; to do this, press both
safety catches at the same time –
cover is unlocked – and remove the
cover
Insert the battery
N Insert battery in the battery
compartment of the machine –
press gently until it clicks into place
– top of battery must be flush with
the top edge of the housing
Switching on the machine
N Assume a firm and secure stance
N Ensure that there are no other
persons within the swivel range of
the machine
Light Emitting Diodes (LED)
on Charger
1
3901BA019 KN
Switching On
3999BA015 KN

Stihl Msa 200 c Specifications

General

Battery Type	Lithium-Ion
Voltage	36 V
Power Source	Battery
Chain Gauge	0.043 in (1.1 mm)
Chain Pitch	1/4 inch
Vibration Level (Front Handle)	2.5 m/s^2
Bar Length	12-14 in. (30-35 cm)
