Stihl Msa 200 c User Manual

MSA 200 C
English
86
1 Battery compartment
2 Chain sprocket
3 Chain brake
4 Guide bar
5 Oilomatic saw chain
6 Chain sprocket cover with quick
chain tensioner
7 Chain catcher
8 Adjusting wheel
9 Handle of wing nut
10 Bumper spike
11 Oil filler cap
12 Front hand guard
13 Front handle (handlebar)
14 Trigger switch lockout
15 Trigger switch
16 Rear handle
17 Rear hand guard
18 Safety catch for locking battery
19 Battery
20 Pushbutton for activating the light-
emitting diodes (LEDs) on the
battery
21 Light-emitting diodes (LEDs) on
battery
22 Charger
23 Light-emitting diode (LED) on
charger
24 Power cord with power plug
# Serial number
Main Parts
2
18
18
19
20
21
9
7
14
15
22
3999BA013 KN
5
4
3
8
10
11
12
1
6
13
16
17
#
24
23

Stihl Msa 200 c Specifications

General

Battery Type	Lithium-Ion
Voltage	36 V
Power Source	Battery
Chain Gauge	0.043 in (1.1 mm)
Chain Pitch	1/4 inch
Vibration Level (Front Handle)	2.5 m/s^2
Bar Length	12-14 in. (30-35 cm)
