Stihl RM 545 - Troubleshooting

0478 111 9940 A - EN
58
Transporting lithium-ion batteries:
RM 545.0 VE: The lithium-ion batteries
used meet the requirements specified in
UN manual ST/SG/AC.10/11/Rev. 5
Part III, subsection 38.3.
The user may carry these batteries to the
place of use of the machine without further
restrictions during road transport.
Country-specific legislation must be
observed in the case of air or sea
transport.
For further transport instructions, see
http://www.stihl.com/safety-data-sheets
18.1 REACH
REACH is an EC Directive for the
registration, evaluation, authorisation and
restriction of chemicals.
Information on compliance with the
REACH Directive (EC) No. 1907/2006 is
available from www.stihl.com/reach.
Fault:
Engine not starting
Possible cause:
– Motorstop lever not pressed.
– RM 545 VE: Battery discharged or
defective.
– No fuel in tank; fuel line blocked.
– Inferior, dirty or old fuel in tank.
–Air filter dirty.
– Spark plug socket detached from spark
plug; ignition lead not properly fastened
to socket.
– Spark plug dirty or damaged; incorrect
electrode gap.
– Lawn mower housing blocked.
Remedy:
– Press motorstop lever to handlebar and
hold. (Ö 9.2)
– RM 545 VE: Charge or replace battery.
(Ö 8.6)
– Top up fuel; clean fuel line. #
– Always use fresh, good quality fuel,
unleaded petrol; clean carburettor. #
– Clean air filter. #
– Connect spark plug socket; check
connection between ignition lead and
socket. #
– Clean or replace spark plug; adjust
electrode gap. #
– Clean lawn mower housing (disconnect
spark plug socket first) and additionally
remove battery on RM 545 VE.
(Ö 12.2)
Fault:
Starting problems or deteriorating engine
power.
Possible cause:
– Lawn mower housing blocked.
– Mowing at an excessively low cutting
height or propulsion speed is too high in
relation to the cutting height.
– Water in fuel tank and carburettor;
carburettor blocked.
– Fuel tank contaminated.
– Air filter dirty.
– Spark plug dirty.
Remedy:
– Clean lawn mower housing (disconnect
spark plug socket first) and additionally
remove battery on
RM 545 VE.(Ö 12.2)
– Select higher cutting height or reduce
pushing speed. (Ö 8.5)
– Empty fuel tank, clean fuel line and
carburettor. #
– Clean fuel tank. #
– Clean air filter. #
– Clean spark plug. #
Fault:
Mowing channel blocked
Possible cause:
– Mowing blade is worn.
Nominal output at
nominal speed
2,4 - 2800
kW - rpm
Starter Rope start
Fuel tank 1,0 l
Cutter bar speed 2800 rpm
Cutting heights 20 - 75 mm
Roller diameter (rear) 90 mm
Roller drive Vario
Weight 30 kg
Sound emissions
In accordance with Directive 2000/14/EC:
Guaranteed sound
power level L
WAd
95 dB(A)
In accordance with Directive 2006/42/EC:
Sound pressure level
at workplace L
pA
82 dB(A)
Uncertainty K
pA
2 dB(A)
Hand-arm vibrations
Specified vibration characteristic in
accordance with EN 12096:
Measured value a
hw
4,20 m/sec²
Uncertainty K
hw
2,10 m/sec²
Measurement in accordance with
EN 20643
RM 545.0 VR:
19. Troubleshooting
# If necessary, contact a specialist
dealer; STIHL recommends STIHL
specialist dealers.
@ See engine instruction manual.
