0478 111 9940 A - EN
● Increasing the driving speed:
Pull Vario drive lever (2)
rearwards when driving.
● Reducing the driving speed:
Push Vario drive lever (2)
forwards when driving.
Switching off self-propulsion:
● Release self-propulsion lever (1). Self-
propulsion is switched off and the lawn
mower comes to a standstill. The
engine continues to run.
11.4 Emptying the grass catcher
box
● Detach the grass catcher box and set it
down. (Ö 8.8)
● Open the grass catcher box at tab (1).
Fold up the upper part of grass catcher
box (2) and hold. Fold the grass catcher
box rearwards and empty the clippings.
The grass catcher box can be held
securely and emptied easily using
handles (3, 4) on the upper and lower
part of the grass catcher box.
● Close the grass catcher box.
● Attach the grass catcher box. (Ö 8.8)
12.1 General
Annual service by the specialist dealer:
The lawn mower should be inspected once
annually by a specialist dealer. STIHL
recommends STIHL specialist dealers.
12.2 Cleaning the machine
Maintenance interval:
After each use
Care of the machine will protect it against
damage and extend its service life.
● Select the highest cutting level. (Ö 8.5)
● Detach the grass catcher box. (Ö 8.8)
● Set down upper handlebar (1)
rearwards.
● Open discharge flap (2) and hold it
open.
● Lift up the machine at the front at
carrying handle (3) and place in the
cleaning position as shown.
Notes on cleaning:
● Clean off dirt using little water, with a
brush or with a cloth. In particular, also
clean the mowing blade. Never spray
water onto engine components, seals
or bearing points.
● First, remove accumulated clipping
deposits using a stick.
● If necessary, use a special cleaner
(e.g. STIHL special cleaner).
12.3 Checking blade wear
Maintenance interval:
Before each use
● Tilt the mower upwards into the
cleaning position. (Ö 12.2)
● Clean mowing blade (1).
● Use a slide calliper to measure blade
thickness A at a minimum of 5 points.
In particular, minimum thickness must
also be ensured in the area of the blade
wings.
Risk of injury!
Before detaching the grass catcher
box, stop the engine and allow the
mowing blade to come to a
standstill.
A completely filled grass catcher
box can weigh up to 16kg.
22
12. Maintenance
Risk of injury!
Observe the safety instructions in
the section "For your safety" (Ö 4.).
Risk of injury!
Stop the engine, detach the spark
plug socket, remove the battery
(with RM 545 VE) and allow the
machine to cool.
Empty the fuel tank (run empty)
before placing the machine in the
cleaning position.
The machine is only safely in the
cleaning position when the
discharge flap is open.
23
Risk of injury!
Blades are subjected to differing
degrees of wear depending on the
location and duration of use. If you
use the machine on sandy ground
or use it frequently under dry
conditions, the blade will be
subjected to greater loads and will
wear more quickly than the
average. A worn blade may break
off and cause serious injuries. The
instructions for blade maintenance
must therefore always be observed.
