Still EXV 14D - Page 153

DIMENSIONS EXV 14 / EXV 16 EXV 14i / EXV 16i
4.2 Height of mast, lowered
h1 (
mm)
1915
(6)
1915
(6)
4.3 Free lift
h2 (
mm)
150
(6)
150
(6)
4.4 Lift
h3 (
mm)
2844
(6)
2844
(6)
4.5 Height of mast, extended
h4 (
mm)
3364
(6)
3364
(6)
4.6
h5
(mm)
/ 110
4.9
Height of tiller arm in driv-
ing position, min/max
h14 (
mm)
865 / 1265 865 / 1265
4.1
5
Fork height, lowered
h13
(mm)
86 86
4.1
9
Overall length without load
l1
(mm)
1950
(2) (4)
1950
(2) (4)
4.2
0
Length including fork
shoulder
l2
(mm)
800
(2) (4)
800
(2) (4)
4.2
1
Total width
b1
(mm)
800 800
4.2
2
Fork dimensions
s/e/
l (m
m)
55
(8)
/182/1150 55
(8)
/182/1150
4.2
4
Fork carriage width
b3
(mm)
780 780
4.2
5
Fork spread
b5
(mm)
560 / 680 560 / 680
4.2
6
b4
(mm)
255 / 375 255 / 375
4.3
2
Ground clearance, centre
of wheelbase
m2
(mm)
30
(9)
20
(9)
/ 150
(3)
4.3
4
Aisle width with pallets 800
x 1200
Ast (
mm)
2465
(4)
/2348
(4) (10)
2448
(3) (4) (11)
/2333
(3) (4)
(10) (11)
4.3
4.1
Aisle width with pallets
1000 x 1200
Ast (
mm)
2503
(4)
/2386
(4) (10)
2462
(3) (4) (12)
/2347
(3) (4)
(10) (12)
4.3
5
Turning radius
Wa (
mm)
1643
(4)
/1526
(4) (10)
1565
(3) (4) (13
)/1450
(3) (4)
(10) (13)
PERFORMANCE EXV 14 / EXV 16 EXV 14i / EXV 16i
5.1
Travel speed with/without
load
km/h 6.0 / 6.0
(15)
6.0 / 6.0
(15)
Technical data
6
Datasheet
14345758043484 EN - 11/2021 - 08
