5.2
Lifting speed, with/without
load
m/s 0.16/0.30/0.15/0.30
(14)
0.16/0.30/0.15/0.30
(14)
5.3
Lowering speed, with/with-
out load
m/s 0.40/0.35/0.40/0.35
(14)
0.40/0.35/0.40/0.35
(14)
5.8
Climbing ability KB 5', with/
without load
% 10.0/23.0
(15)
10 (8)
(19)
/22
5.1
0
Service brake Electric Electric
TRANSMISSION
EXV 14 / EXV 16 EXV 14i / EXV 16i
6.1 Traction motor, S2=60 min kW 2.3 - 1.5
(20)
2.3 - 1.5
(20)
6.2 Lifting motor, S3=15% kW 3.2 3.2
6.3
Battery acc. to DIN 43
531/35/36 A, B, C, no
2 PzS 2 PzS
6.4 Voltage/Nominal capacity V/Ah 24 / 230 24 / 230
6.5 Battery weight (±5%) kg 212 212
6.6
Energy consumption acc.
to VDI cycle
kWh/
h
1.14/1.15 1.24/1.25
OTHER
EXV 14 / EXV 16 EXV 14i / EXV 16i
8.1 Type of drive control AC control AC control
8.4
Noise level at operator's
ear
dB
(A)
≤ 66 ≤ 66
(1) In brackets: capacity on the forks for the
version with fork initial lift (i)
(2) Values for Tele or NiHo mast (x value
-26 mm, l
1
+ l
2
+26 mm with Triplex mast)
(3) Fork arms raised (see the figure with apos-
trophe for dimensions)
(4) Value with battery such as 6.3 (+75 mm
with 3 PzS and +150 mm with 4PzS)
(5) Truck with tandem rollers
(6) Value with Tele mast h
3
= 2844 mm. For
other values see mast table
(7) With load rack, mandatory for -SF
(8) Value with platform lowered
(9) The fork thickness value indicated is for
use with GITTER-BOX. A carriage with thick-
ness s = 71 mm is also available
(10) Thickness values with forks fully lowered
m
2
= 15 mm
Technical data
6
